Migrating from Citrix NetScaler to HAProxy: A Complete Guide

When faced with aging NetScaler appliances and expensive renewal costs, many organizations are looking for alternatives. This guide documents a real-world migration from Citrix NetScaler to HAProxy on Ubuntu 24.04 (can be RedHat), preserving critical functionality like content switching and SSL offloading.

Why Migrating Was Necessary

In my case, there were two major blockers that forced the move away from NetScaler:

• Freemium throughput limitation: The VPX freemium edition is capped at 20 Mb/s, which was a real bottleneck for modern workloads.
• Hardware failure: My NetScaler SDX 11500 appliance died, leaving me with only the two VPX instances running on proxmox and those were both constrained by the freemium license limits.

That combination meant I needed a serious, production-ready alternative that could replace the NetScaler VPX instances without throughput restrictions, licensing headaches, or dependence on proprietary hardware.

Understanding the Starting Point

The NetScaler configuration revealed a typical setup:

• Content Switching: Routing traffic to different backends based on hostname
• SSL Offloading: Handling TLS termination with multiple wildcard certificates
• Load Balancing: Distributing traffic across Docker Swarm nodes
• Health Monitoring: Various HTTP/HTTPS checks with custom parameters

The configuration served 18 different services across three domains with traffic distributed across multiple Docker hosts.

Why HAProxy?

After evaluating alternatives including NGINX, Traefik and F5 BIG-IP, HAProxy emerged as the optimal choice because:

• Configuration concepts map directly from NetScaler
• Production-proven at scale
• Robust health checking capabilities
• Excellent SSL/SNI support
• Open source with strong community

Installation Process

Step 1: Installing HAProxy on Ubuntu 24.04

sudo apt update
sudo apt install haproxy
sudo systemctl enable haproxy

Step 2: Preparing SSL Certificates

NetScaler stores certificates and keys separately, while HAProxy requires combined PEM files:

sudo mkdir -p /etc/haproxy/certs

# For each certificate, combine cert and key
openssl rsa -in domain.key -out temp.key.nopass
cat domain.crt temp.key.nopass > /etc/haproxy/certs/domain.pem

sudo chmod 400 /etc/haproxy/certs/*.pem
sudo chown haproxy:haproxy /etc/haproxy/certs/*.pem

Configuration Translation

NetScaler to HAProxy Mapping

The Configuration Structure

The HAProxy configuration follows this pattern:

global
    # System-wide settings
    log 127.0.0.1:514 local0
    user haproxy
    group haproxy

defaults
    # Default parameters for all proxies
    mode http
    timeout client 180s
    timeout server 360s

frontend https_frontend
    bind *:443 ssl crt /etc/haproxy/certs/

    # Content switching ACLs
    acl host_app1 hdr(host) -i app1.example.com
    acl host_app2 hdr(host) -i app2.example.com

    # Route to appropriate backend
    use_backend app1_backend if host_app1
    use_backend app2_backend if host_app2

backend app1_backend
    balance roundrobin
    server node01 10.0.1.10:3000 check
    server node02 10.0.1.11:3000 check

backend app2_backend
    balance roundrobin
    server node01 10.0.1.10:8080 check
    server node02 10.0.1.11:8080 check

Key Challenges and Solutions

Challenge 1: SSL Certificate Format

Problem: NetScaler uses separate certificate and key files, HAProxy needs combined PEM files.
Solution: Automated script to combine certificates with keys after removing passphrases.

Challenge 2: Health Check Syntax

Problem: HAProxy 2.8 deprecated inline headers in httpchk.
Solution: Used new http-check send syntax with explicit method and headers:

http-check send meth HEAD uri / hdr Host app.example.com

Challenge 3: Multiple Acceptable Status Codes

Problem: Some services return 302 or 405 as valid responses.
Solution: Used regex patterns in health checks:

http-check expect rstatus (200|302|405)

Challenge 4: IP Binding Issues

Problem: Initial config tried to bind to IPs not present on the server.
Solution: Used wildcard binding for main services, specific IPs only when necessary.

Challenge 5: Home Assistant Behind HAProxy

Problem: Requests to Home Assistant returned HTTP 400 Bad Request because HA saw duplicated or untrusted X-Forwarded-For headers.
Solution:

• Removed duplicate header injection (option forwardfor or manual http-request set-header X-Forwarded-For, not both).
• Added timeout tunnel 1h in HAProxy defaults to keep WebSocket connections alive.

Configured Home Assistant to trust the proxy in HAS configuration.yaml:

http:
  use_x_forwarded_for: true
  trusted_proxies:
    - 192.168.89.125    # HAProxy IP

Challenge 6: Outline (Outliner) Behind HAProxy

Problem: Outline (the collaborative docs app) returned 500 errors during health checks and login redirects failed.
Solution:

• Once FORCE_HTTPS was enabled, Outline behaved correctly behind HAProxy.

Adjusted the application’s Docker Compose environment:

URL=https://docs.example.com
FORCE_HTTPS=true

Added proper Host header in health checks:

http-check send meth GET uri / hdr Host docs.example.com
http-check expect rstatus (200|301|302|401)

What You Cannot Migrate

One important limitation: Citrix Gateway (NetScaler Gateway) cannot be migrated to HAProxy.

• NetScaler Gateway provides full ICA Proxy, VPN and authentication gateway features for Citrix Virtual Apps and Desktops.
• HAProxy is strictly a reverse proxy and load balancer; it does not implement Citrix’s ICA proxying or VPN gateway functionality.
• If your NetScaler is used as a Citrix Gateway, you will need to keep it, replace it with another Citrix ADC, or move to alternative VPN/remote access solutions.
• HAProxy is excellent for content switching, SSL offload and load balancing web applications but it is not a replacement for NetScaler Gateway.

Feature Comparison: NetScaler vs HAProxy

Migration Execution

Phase 1: Parallel Running

1. Set up HAProxy on new server.
2. Tested with hosts file entries before DNS changes.
3. Monitored logs for issues.

Phase 2: Traffic Cutover

1. Updated my firall rule to switch from Netscaler Content Switching VIP to point to HAProxy.
2. Monitored both old and new systems.
3. Gradual service migration.

Phase 3: Decommissioning

1. Confirmed all traffic on HAProxy.
2. Exported any remaining NetScaler configs.
3. Decommissioned NetScaler appliances.

Monitoring and Validation

Essential monitoring commands post-migration:

# Check backend health
echo "show stat" | sudo socat stdio /run/haproxy/admin.sock

# Monitor real-time traffic
sudo tail -f /var/log/haproxy.log

# Verify certificate loading
openssl s_client -connect localhost:443 -servername app.example.com

Performance Comparison

The migration resulted in:

• Cost: 100% reduction in licensing fees
• Performance: Comparable request handling with lower memory footprint
• Flexibility: Easier configuration updates without GUI
• Maintenance: Simplified with standard Linux tooling

Lessons Learned

1. Test thoroughly: Use a staging environment matching production.
2. Certificate management: Establish a process for certificate updates.
3. Health checks: Ensure health check expectations match actual service behavior.
4. Documentation: Map every NetScaler feature to its HAProxy equivalent before starting.
5. Proxy-aware apps need tuning: Some apps (Home Assistant, Outline) require explicit configuration of trusted_proxies or HTTPS enforcement.
6. Citrix Gateway is not replaceable: HAProxy cannot serve as a Citrix Gateway; plan alternatives if you use ICA Proxy/VPN.
7. Chroot considerations: Initially disabled chroot to avoid binding issues; can be re-enabled with proper configuration.
8. Freemium limits hurt: The 20 Mb/s throughput limit on NetScaler VPX freemium makes it unusable for production. Combined with SDX hardware failure, it was the trigger to migrate.

Common Gotchas

• Private key passwords: HAProxy cannot handle password-protected keys at runtime.
• Certificate order: Must be certificate, intermediate (if any), then private key in PEM files.
• Health check methods: Some applications reject HEAD requests; adjust to GET when needed.
• Session persistence: Different syntax from NetScaler but same concepts apply.

Migrating from NetScaler to HAProxy is entirely feasible for most load balancing and content switching scenarios. The key is understanding the configuration mapping and preparing certificates properly. While you lose the GUI and some enterprise features, you gain flexibility, cost savings and a solution that integrates naturally with modern infrastructure automation.

The complete configuration serves 18 services across multiple domains, handles SSL termination with SNI and provides the same content-based routing previously handled by NetScaler all on a simple Ubuntu VM with HAProxy.

For organizations evaluating alternatives to expensive commercial load balancers, HAProxy provides a production-ready solution that can handle enterprise workloads while maintaining familiar concepts for network administrators.
