In the same way as the previous blog post, some more automation to maintain a VDI/RDSH environment, and get back to a controlled and clean environment. This blog is a follow up to Remotely clean up Virtual Machines drives – XenDesktop , Expand virtual machines hard disk – automation , XenDesktop XenApp 7.x – vmware / ad / delivery group notes and descriptions sync . I had to automate an action to place ACLs on the D: drive using Powershell and icacls. This script is using XenDesktop / XenApp command to list all the Virtual Machines with SessionSupport value equal to SingleSession, it means the VDI only in my case. If you want to check the list of Virtual Machines you targeted you can use this command : If you want to target a specific XenDesktop Delivery Group, then just adapt the previous line : Once you know the target, you can execute the following script. Using this script assume Virtual Machines are switched on. If you have suggestion, and/or comment, share your though !
Following up the previous blogs XenDesktop XenApp 7.x – vmware / ad / delivery group notes and descriptions sync and Expand virtual machines hard disk – automation and continue in automated task, I had to clean up the D: drive of different XenDesktop Delivery Group. As there was no security restriction on the D: drive some users used it as a repository for some of their project... That caused some issues : Users complain of losing their working data from a session to another (pooled VDI, new logon = new vm) Some disk space notification where displayed to random users... Calls where raise to the helpdesk support team Beside hiding the D: drive to avoid non necessary access (ie : non system access) check this blog to do so : Citrix XenApp – Hiding system drives part 1/2 an automated task had to be performed to "clean" this D: drive The variable $XDDC is the FQDN of a Delivery Controler, $Exclusion is the files and folder you want to exclude from being removed. For example : the directories "logs" "pvsvm" "System Volume Information" "$RECYCLE.BIN" and the files "dedicateddumpfile.sys" "pagefile.sys" and "vdiskdif.vhdx" will be ignore from the delete process. Most of these files and directory are system protected anyway it's more to avoir error during script execution. Once you have a clear list of what you need and want to keep you can proceed to the next step. This script will clean everything which is not in the $Exclusion list so be careful when you run the script. This script assume all the targeted VM are switched ON of course. Leave a comment bellow if you have an idea how to improve this script !
Sometimes, at some customers's place, with an infrastructure already in place (XenApp with PVS or XenDesktop VDI pooled with PVS) the D: drive is too small. The drive where you redirect Windows Event Logs, Logs (UPM for example and/or other applications - services) This is a drive where page file is often redirected as well and even memory dump file generated. PVS cache can also be on this drive : Cache on device RAM with overflow on Hard Disk When RAM is zero, the target device write cache is only written to the local disk. When RAM is not zero, the target device write cache is written to RAM first. When RAM is full, the least recently used block of data is written to the local Write Cache disk to accommodate newer data on RAM. The amount of RAM specified is the non-paged kernel memory that the target device consumes. Cache on device Hard Disk The cache on local HD is stored in a file on a secondary local hard drive of the device. It gets created as an invisible file in the root folder of the secondary local HD. The cache file size grows, as needed, but never gets larger than the original vDisk, and often not larger than the free space on the original vDisk. It is slower than RAM cache, but faster than Server cache and works in a HA environment. The lack of space on this drive will bring some slowness in user's session and this drive needs to be expanded a bit to get back a normal user experience. To expand these disks two actions need to be done : Expand the Virtual Machine hard disk - in this example vmware Virtual Machines Expand the disk within the Operation System (Windows) In addition to the following script, psexec tool (Microsoft Sysinternal) is used to execute remotely the diskpart command listed in a text file (diskpart.txt) which is upload to the Virtual Machines. Targeted Virtual Machines need to be powered on. Psexec.exe and Diskpart.txt needs to be in the same folder as the Powershell script, of course you can specify their path as it suits your need. This script is using XenDesktop / XenApp command to list all the Virtual Machines with SessionSupport value equal to SingleSession, it means the VDI only in my case. If you want to check the lust of Virtual Machines…
Several times i had the need to synchronise Virtual Machine notes (vmware) with Active Directory Computer description. As in big environment, different team are managing each of these components, the need to be able to link an Active Directory computer account to a vm with XenApp / XenDesktop delivery group has often been seen as useful. Delivery group name : Desktop123 Virtual Machine note (vmware) : Desktop123 Active Directory account Description : Desktop123 The idea is to simply synchronise the information through the platforms so everyone knows quickly what machine does what. In this particular example that was about XenApp Servers and XenDesktop VDI. You will need a machine where : XenDesktop 7.x SDK (Powershell is installed) vmware PowerCli installed RSAT role deployed as well Thank to Rodolphe Herpeux who simplified the first version of this script I wrote.
This is a classic but needs to be written somewhere so I can find it again when I need it ! First thing, you need to add the XenApp Powershell snapin : Then you can use few very useful command to gather information and script your deployment / inventory. That's what you got access to, now I want to list hotfixes on XenApp servers, I used Get-XaServerHotfix "ServerName" The result format is not very useful and is about only 1 server in a farm of 100... And I was looking for all the servers which had the XA650R01W2K8R2X64061 hotfix installed I needed to have a list of all servers, only the machine name where this hotfix was installed. And the result look like this : This is simple and quite basic but it's very useful ! if you have any comment and/ or request, just drop me an email or comment !
So auto-install and auto join an already XenDesktop 7 Site is cool but what if you need to automate the first DDC installation ? Here is how I did with help of a great blog (Timm Brochhaus) who made a script available for everyone, and I personally used it. Let's do it for a full automated installation, I will install all the components from XenDesktop 7. Timm Brochhaus wrote a very cool blog and give you the explanation about a script he wrote to automate this part with a very useful script. Juts don't forget to run this script in 32bit mode.... [link] I did use Timm's script and here is the result I got : 3 databases were created, one for the Site informations, one for the log informations and a last one for monitoring (edgesight-like) Now we are ready for the next step which is site creation with the command New-XDSite with the result : If I use the script Timm make available and use the same syntax, this is pretty easy to add this line and add what we need to automate DataBase creation + Site creation in one script : So now your XenDesktop 7 DDC is ready to work, you can launch the Desktop Studio console, you just need to create your Machine Catalogs and Delivery Groups etc... This next part of automation is in my next blog about XenDesktop 7
I installed one AD when Microsoft Windows Server 2012 was still in Release Candidate with the Datacenter edition, of course since few days my DC was rebooting every hour, the trial licence did expire few days ago.. So I had to install a new DC and promote it the transfer all FSMO roles from my "old" server to the new one. First thing I had to do is to add this new server to the existing forest as a new domain controller : I did it using the gui but you can also use PowerShell to get the same result : Now the server has been added to the forest as a new domain controller, on the new server after launching PowerShell command line, i used the Move-ADDirectoryServerOperationMasterRole command to transfer all the FSMO roles. EAch role corresponding to a number : Role Name Number PDCEmulator 0 RIDMaster 1 InfrastructureMaster 2 SchemaMaster 3 DomainNamingMaster 4 So my command line looked like that This is it ! Don't forget to demote the "old" domain controller before getting rid of it. I wanted to blog about that because I'm not manipulating Active Directory controller every day and here is my scratch notebook so, this is to keep track on what I'm doing and share information.
