Cloudify my lab with Windows Azure 13 Comments

As I got an unlimited access to Windows Azure I wanted to check out how I could extend my lab into it and use it to store VMs workload (at first). Here what you need : Citrix NetScaler VPX (tested with NS10.1: Build 122.17.nc & NS10.1: Build 123.9.nc) Windows Azure Access Homelab (running on vSphere 5.5) Of course, you need licence for everything... Considerations : Before configuring a CloudBridge tunnel between a CloudBridge appliance in datacenter and  Microsoft Azure, consider the following points: The CloudBridge appliance must have a public facing IPv4 address (type SNIP) to use as a tunnel end-point address for the CloudBridge tunnel. Also, the CloudBridge appliance should not be behind a NAT device. (or you'll have to setup a route for your LAN computers, I'm explaining how to at the end of this blog) Azure supports the following IPSec settings for a CloudBridge tunnel. Therefore, you must specify the same IPSec settings while configuring the CloudBridge appliance for the CloudBridge tunnel. IKE version = v1 Encryption algorithm = AES Hash algorithm = HMAC SHA1  You must configure the firewall in the datacenter edge to allow the following. Any UDP packets for port 500 Any UDP packets for port 4500 Any ESP (IP protocol number 50) packets IKE re-keying, which is renegotiation of new cryptographic keys between the CloudBridge tunnel end points to establish new SAs, is not supported. When the Security Associations  (SAs) expire, the tunnel goes into the DOWN state. Therefore, you must set a very large value for the lifetimes of SAs. You must configure Microsoft Azure before specifying the tunnel configuration on the CloudBridge appliance, because the public IP address of the Azure end (gateway) of the tunnel, and the PSK, are automatically generated when you set up the tunnel configuration in Azure. You need this information for specifying the tunnel configuration on the CloudBridge appliance. First thing first, you need to use your Windows Azure account and follow the next step to begin to configure the IPSec tunnel by creating a local network In the left pane, click NETWORKS. In the lower left-hand corner of the screen, click + NEW. In the NEW navigation pane, click NETWORK, then click VIRTUAL NETWORK, and then click ADD LOCAL NETWORK. In the ADD A LOCAL NETWORK wizard, in the specify your local network details screen, set the following parameters: NAME  VPN DEVICE IP ADDRESS In the lower right corner of the screen,…

Today I needed to enable SNMP on my XenServer lab at home, I was looking for an efficient way to monitor my XenServer. I found a Linux distribution very handy for a Cacti box, EZCacti, you can download it here : http://cactiez.cactiusers.org/download/ So to enable SNMP on XenServer 6, you need to follow the following guide. Please keep in memory you shouldn't do that on your XenServer in a production environment, Citrix won't be able to bring support if you modify the dom0. First step, you need to allow SMTP to be able to collect and allow Cacti to get information from SNMP on the port 161/UDP : Edit the file /etc/sysconfig/iptables with vi and add the following line : and then restart the iptables service using the following command line : service iptables restart Now you need to configure your SNMP settings (community etc...) by editing the following file with vi : /etc/snmp/snmpd.conf Make the change on your smtpd.conf file on the two line (in red) you can find in the example above, of course you'll need to change the IP range to match your network subnet. Now you need to start the SNMP service using the following command line : service snmpd start Finally, to enable the automatic start of the SNMP service at your XenServer startup, type : chkconfig snmpd on Now I can begin to work on Cacti and try to monitor the host and the VMs (Next blog to come)
